# coding=utf-8
# ======================================
# File: backtest.py
# Author: Jackie PENG
# Contact: jackie.pengzhao@gmail.com
# Created: 2024-03-12
# Desc:
# Functions used for backtesting.
# ======================================
import logging
import time
import pandas as pd
import numpy as np
from numba import njit
from typing import Any, Union, Optional
from numpy import bool_, dtype, ndarray
from pandas import DataFrame
from qteasy.finance import CashPlan
from qteasy.utilfuncs import (
str_to_list,
FunctionTimer,
)
from qteasy.qt_operator import (
Operator,
SIGNAL_TYPE_ID,
)
from qteasy.evaluate import (
evaluate,
)
from qteasy.finance import (
apply_execution_slippage,
get_selling_result,
get_purchase_result,
)
from qteasy.visual import (
_plot_loop_result,
_loop_report_str,
)
from qteasy.trading_util import (
parse_pt_signals,
parse_ps_signals,
parse_vs_signals,
trim_pt_type_signals,
sell_direction_adjustment,
buy_direction_adjustment,
)
@njit(nogil=True, cache=True)
def backtest_step(
signal_type: Union[int, np.int32, np.int64, np.ndarray],
op_signal: np.ndarray,
cash_inflation: np.ndarray,
is_delivery_day: bool,
day_num: Union[int, np.int32, np.int64, np.ndarray],
own_cash: np.ndarray,
own_amounts: np.ndarray,
available_cash: np.ndarray,
available_amounts: np.ndarray,
trade_prices: np.ndarray,
cost_params: np.ndarray,
pt_buy_threshold: float,
pt_sell_threshold: float,
long_pos_limit: float,
short_pos_limit: float,
allow_sell_short: bool,
moq_buy: float,
moq_sell: float,
cash_delivery_queue: np.ndarray,
stock_delivery_queue: np.ndarray,
cash_delivery_period: int,
stock_delivery_period: int,
share_count: int,
):
""" 完成一次完整的单步骤回测计算，包括下面三个步骤：
1，检查现金增值比例，如果大于0，则更新持有现金和可用现金
2，调用calculate_trade_results()函数计算本次交易结果
3，处理现金变动和持仓变动的交割，更新持有现金和可用现金，更新持有资产和可用资产
更新账户现金和持仓余额后，返回交易后的各项数据和交割队列
Parameters
----------
signal_type: int
信号类型:
0 - PT signal
1 - PS signal
2 - VS signal
op_signal: np.ndarray
本次交易的个股交易信号
cash_inflation: float
现金增值比例
is_delivery_day: bool
是否为新的交割日，用于确定是否需要更新交割队列
day_num: int
当前的天数，用于确定交割队列中的交割位置
own_cash: float
本次交易开始前持有的现金余额（包括交割中的现金）
own_amounts: np.ndarray
本次交易开始前持有的资产份额（包括交割中的资产份额）
available_cash: float
本次交易开始前账户可用现金余额（交割中的现金不计入余额）
available_amounts: np.ndarray:
交易开始前各个股票的可用数量余额（交割中的股票不计入余额）
trade_prices: np.ndarray
本次交易发生时各个股票的交易价格
cost_params: np.ndarray
交易成本参数，包括买入费率、卖出费率、最低买入费用、最低卖出费用、交易滑点
buy_rate: float, 交易成本：买入费率
sell_rate: float, 交易成本：卖出费率
buy_min: float, 交易成本：最低买入费用
sell_min: float, 交易成本：最低卖出费用
slippage: float, 交易成本：交易滑点
pt_buy_threshold: float
当交易信号类型为PT时，用于计算买入/卖出信号的强度阈值
pt_sell_threshold: float
当交易信号类型为PT时，用于计算买入/卖出信号的强度阈值
long_pos_limit: float
允许建立的多头总仓位与净资产的比值，默认值1.0，表示最多允许建立100%多头仓位
short_pos_limit: float
允许建立的空头总仓位与净资产的比值，默认值-1.0，表示最多允许建立100%空头仓位
allow_sell_short: bool
True: 允许买空卖空
False: 只允许买入多头仓位
moq_buy: float:
投资产品最小买入交易单位，moq为0时允许交易任意数额的金融产品，moq不为零时允许交易的产品数量是moq的整数倍
moq_sell: float:
投资产品最小买入交易单位，moq为0时允许交易任意数额的金融产品，moq不为零时允许交易的产品数量是moq的整数倍
cash_delivery_queue: np.ndarray
现金交割队列
stock_delivery_queue: np.ndarray
股票交割队列
cash_delivery_period: int
现金交割周期
stock_delivery_period: int
股票交割周期
share_count: int
交易的股票数量
Returns
-------
tuple: (next_own_cash, next_available_cash, next_own_amounts, next_available_amounts,
current_trade_records, current_trade_cost, cash_delivery_queue, stock_delivery_queue)
next_own_cash: float
本次交易结束后持有的现金余额（包括交割中的现金）
next_available_cash: float
本次交易结束后账户可用现金余额（交割中的现金不计入余额）
next_own_amounts: np.ndarray
本次交易结束后持有的资产份额（包括交割中的资产份额）
next_available_amounts: np.ndarray
交易结束后各个股票的可用数量余额（交割中的股票不计入余额）
current_trade_records: np.ndarray
本次交易的交易记录
current_trade_cost: np.ndarray
本次交易的交易费用
cash_delivery_queue: np.ndarray
更新后的现金交割队列
stock_delivery_queue: np.ndarray
更新后的股票交割队列
"""
# 1，如果现金增值比例大于0，则更新持有现金和可用现金
if cash_inflation > 1.:
own_cash *= cash_inflation
available_cash *= cash_inflation
# DEBUG
# print(f'cash inflation applied: {cash_inflation:.4f}, new own_cash: {own_cash:.2f},
# new available_cash: {available_cash:.2f}')
# print(f'\ncalculating trade results for day {day_num}, signal_type: {signal_type}, op_signal: {op_signal}')
# if day_num == 1781:
# import pdb; pdb.set_trace()
# 2，调用backtest_step函数，计算本次交易的现金变动、持仓变动和交易费用
cash_gained, cash_spent, amount_purchased, amount_sold, fees = calculate_trade_results(
signal_type=signal_type,
own_cash=own_cash,
own_amounts=own_amounts,
available_cash=available_cash,
available_amounts=available_amounts,
op_signal=op_signal,
prices=trade_prices,
cost_params=cost_params,
pt_buy_threshold=pt_buy_threshold,
pt_sell_threshold=pt_sell_threshold,
long_pos_limit=long_pos_limit,
short_pos_limit=short_pos_limit,
allow_sell_short=allow_sell_short,
moq_buy=moq_buy,
moq_sell=moq_sell,
cash_delivery_period=cash_delivery_period,
)
# DEBUG
# print(f'calculated trade results'
# f'own_cash: {own_cash:.5f}, own_amounts: {own_amounts.round(6)}, \n'
# f'available_cash: {available_cash:.5f}, available_amounts: {available_amounts.round(6)}\n'
# f'trade results - cash_gained: {cash_gained.sum():.5f}, cash_spent: {cash_spent.sum():.5f}, '
# f'amount_purchased: {amount_purchased.sum():.5f}, amount_sold: {amount_sold.sum():.5f}, '
# f'fees: {fees.sum():.5f}')
# 3，处理现金变动和持仓变动的交割，输出交割数据
new_cash = cash_gained.sum()
delivered_cash, delivered_stocks = process_backtest_delivery(
cash_delivery_queue=cash_delivery_queue,
stock_delivery_queue=stock_delivery_queue,
is_new_day=is_delivery_day,
day_num=day_num,
new_cash=new_cash,
new_stocks=amount_purchased,
cash_delivery_period=cash_delivery_period,
stock_delivery_period=stock_delivery_period,
share_count=share_count,
)
# DEBUG
# print(f'\nprocessing delivery for day {day_num}, is_delivery_day: {is_delivery_day}\n'
# f'cash delivery queue: {cash_delivery_queue.round(6)}, stock delivery queue: '
# f'{stock_delivery_queue.round(6)}\n delivered_cash: {delivered_cash:.2f}, '
# f'delivered_stocks: {delivered_stocks}')
# 4, 更新持有现金和可用现金
next_own_cash = np.round(own_cash + cash_gained.sum() + cash_spent.sum(), 3)
next_available_cash = np.round(available_cash + delivered_cash + cash_spent.sum(), 3)
# DEBUG
# print(f'updating cash for day {day_num}, \n'
# f'own_cash: {own_cash:.2f} + cash_gained: {cash_gained.sum():.2f} + cash_spent: '
# f'{cash_spent.sum():.2f} = next_own_cash: {next_own_cash:.2f}\n'
# f'available_cash: {available_cash:.2f} + delivered_cash: {delivered_cash:.2f} + cash_spent: '
# f'{cash_spent.sum():.2f} = next_available_cash: {next_available_cash:.2f}')
# 更新持有资产和可用资产
next_own_amounts = np.round(own_amounts + amount_purchased + amount_sold, 3)
next_available_amounts = np.round(available_amounts + delivered_stocks + amount_sold, 3)
# DEBUG
# print(f'updating amounts for day {day_num}, \n'
# f'own_amounts: {own_amounts.round(6)} + amount_purchased: {amount_purchased} + amount_sold: '
# f'{amount_sold} = next_own_amounts: {next_own_amounts.round(6)}\n'
# f'available_amounts: {available_amounts.round(6)} + delivered_stocks: {delivered_stocks} + amount_sold: '
# f'{amount_sold} = next_available_amounts: {next_available_amounts.round(6)}')
# 5, 记录交易记录和交易费用
current_trade_records = amount_purchased + amount_sold
current_trade_cost = fees
return (
next_own_cash,
next_available_cash,
next_own_amounts,
next_available_amounts,
current_trade_records,
current_trade_cost,
cash_delivery_queue,
stock_delivery_queue,
)
@njit(cache=True, nogil=True)
def calculate_trade_results(
signal_type: Union[int, np.int32, np.int64, np.ndarray],
own_cash: Union[float, np.float64, np.ndarray],
own_amounts: np.ndarray,
available_cash: Union[float, np.float64, np.ndarray],
available_amounts: np.ndarray,
op_signal: np.ndarray,
prices: np.ndarray,
cost_params: np.ndarray,
pt_buy_threshold: float,
pt_sell_threshold: float,
long_pos_limit: float,
short_pos_limit: float,
allow_sell_short: bool,
moq_buy: float,
moq_sell: float,
cash_delivery_period: int,
) -> tuple[ndarray, ndarray, ndarray, ndarray, ndarray]:
""" 该函数用于批量计算股票交易结果，根据交易信号、价格和持仓情况，结合交易
成本和仓位限制，计算出每只股票的买入卖出数量、现金变动及交易费用。支持多种
交易信号类型（PT、PS、VS）和做空机制，并通过Numba加速计算。
Parameters
----------
signal_type: int
信号类型:
0 - PT signal
1 - PS signal
2 - VS signal
own_cash: float
本次交易开始前持有的现金余额（包括交割中的现金）
own_amounts: np.ndarray
本次交易开始前持有的资产份额（包括交割中的资产份额）
available_cash: np.ndarray
本次交易开始前账户可用现金余额（交割中的现金不计入余额）
available_amounts: np.ndarray:
交易开始前各个股票的可用数量余额（交割中的股票不计入余额）
op_signal: np.ndarray
本次交易的个股交易信号
prices: np.ndarray，
本次交易发生时各个股票的交易价格
cost_params: np.ndarray
交易成本参数，包括固定买入费用、固定卖出费用、买入费率、卖出费率、最低买入费用、最低卖出费用
buy_rate: float, 交易成本：固定买入费率
sell_rate: float, 交易成本：固定卖出费率
buy_min: float, 交易成本：最低买入费用
sell_min: float, 交易成本：最低卖出费用
slippage: float, 交易成本：滑点
pt_buy_threshold: object Cost
当交易信号类型为PT时，用于计算买入/卖出信号的强度阈值
pt_sell_threshold: object Cost
当交易信号类型为PT时，用于计算买入/卖出信号的强度阈值
long_pos_limit: float
允许建立的多头总仓位与净资产的比值，默认值1.0，表示最多允许建立100%多头仓位
short_pos_limit: float
允许建立的空头总仓位与净资产的比值，默认值-1.0，表示最多允许建立100%空头仓位
allow_sell_short: bool
True: 允许买空卖空
False: 默认值，只允许买入多头仓位
moq_buy: float:
投资产品最小买入交易单位，moq为0时允许交易任意数额的金融产品，moq不为零时允许交易的产品数量是moq的整数倍
moq_sell: float:
投资产品最小买入交易单位，moq为0时允许交易任意数额的金融产品，moq不为零时允许交易的产品数量是moq的整数倍
cash_delivery_period: int:
资金交割周期，单位为天
Returns
-------
tuple: (cash_gained, cash_spent, amounts_purchased, amounts_sold, fee)
cash_gained: ndarray, 本批次交易中获得的现金增加额
cash_spent: ndarray, 本批次交易中共花费的现金总额
amounts_purchased: ndarray, 交易后每个个股账户中的股份增加数量
amounts_sold: ndarray, 交易后每个个股账户中的股份减少数量
fee: ndarray, 本次交易每个个股的交易费用，包括卖出的费用和买入的费用
"""
# 1,计算期初资产总额：交易前现金及股票余额在当前价格下的资产总额
pre_values = own_amounts * prices
total_value = own_cash + pre_values.sum()
empty_array = np.zeros_like(op_signal)
# 2,制定交易计划，生成交易意图（计划买入金额和计划卖出数量）
if signal_type == 0: # PT信号
# 限定PT信号在多空持仓限额范围内，这样就不需要在后续处理交易指令时调整交易数量了
trimmed_op_signal = trim_pt_type_signals(
op_signals=op_signal,
long_pos_limit=long_pos_limit,
short_pos_limit=short_pos_limit,
)
cash_to_spend, amounts_to_sell = parse_pt_signals(
signals=trimmed_op_signal,
prices=prices,
own_amounts=own_amounts,
own_cash=own_cash,
pt_buy_threshold=pt_buy_threshold,
pt_sell_threshold=pt_sell_threshold,
allow_sell_short=allow_sell_short
)
# DEBUG
# print(f'parsed PT signals, trimmed_op_signal: {trimmed_op_signal.round(3)}, \n'
# f'cash_to_spend: {cash_to_spend.round(2)}, amounts_to_sell: {amounts_to_sell.round(2)}')
elif signal_type == 1: # PS信号
cash_to_spend, amounts_to_sell = parse_ps_signals(
signals=op_signal,
prices=prices,
own_amounts=own_amounts,
own_cash=own_cash,
allow_sell_short=allow_sell_short
)
# 如果是全零信号，则直接返回空结果
if np.allclose(cash_to_spend, 0.) and np.allclose(amounts_to_sell, 0.):
return (empty_array,
empty_array,
empty_array,
empty_array,
empty_array)
elif signal_type == 2: # VS信号
cash_to_spend, amounts_to_sell = parse_vs_signals(
signals=op_signal,
prices=prices,
own_amounts=own_amounts,
allow_sell_short=allow_sell_short,
cost_params=cost_params,
)
# 如果是全零信号，则直接返回空结果
if np.allclose(cash_to_spend, 0.) and np.allclose(amounts_to_sell, 0.):
return (empty_array,
empty_array,
empty_array,
empty_array,
empty_array)
else:
raise ValueError('Invalid signal_type')
# # 这里还需要考虑交易价格为NaN的情况，如果价格为NaN，则不进行交易，直接将交易计划中的买入金额和卖出数量调整为0
# cash_to_spend = np.where(np.isnan(prices), 0, cash_to_spend)
# amounts_to_sell = np.where(np.isnan(prices), 0, amounts_to_sell)
# 3, Operator 级卖出方向调整（可用持仓 / 卖空超额转化；空头超额转多头时含买入佣金预算）
cash_to_spend, amounts_to_sell = sell_direction_adjustment(
cash_to_spend,
amounts_to_sell,
own_amounts,
available_amounts,
prices,
allow_sell_short,
cost_params,
)
# DEBUG
# print(f'Processed signals, calculated and adjusted'
# f'\ncash_to_spend: {cash_to_spend.round(2)}, \namounts_to_sell: {amounts_to_sell.round(2)}')
# 4，批量提交股份卖出计划，计算实际卖出份额和交易费用
amount_sold, cash_gained, fee_selling = get_selling_result(
prices=prices,
a_to_sell=amounts_to_sell,
moq=moq_sell,
cost_params=cost_params,
)
# DEBUG
# print(f'calculated amount sell result:\n'
# f'amount sold: {amount_sold.round(2)}\n'
# f'cash gained: {cash_gained.round(2)}')
if np.allclose(cash_to_spend, 0.0, atol=0.001):
# 如果所有买入计划绝对值都小于1分钱，则直接跳过后续的计算
return cash_gained, empty_array, empty_array, amount_sold, fee_selling
# 5，买入方向调整（可用现金 / 多空限额；PT 且交割为 0 时可复用本期卖出现金）
avail_cash_f = float(available_cash)
cash_to_spend = buy_direction_adjustment(
cash_to_spend,
int(signal_type),
int(cash_delivery_period),
avail_cash_f,
cash_gained,
amount_sold,
own_amounts,
prices,
long_pos_limit,
short_pos_limit,
allow_sell_short,
float(total_value),
)
# 批量提交股份买入计划，计算实际买入的股票份额和交易费用dflasjdf
# 由于已经提前确认过现金总额，因此不存在买入总金额超过持有现金的情况
amount_purchased, cash_spent, fee_buying = get_purchase_result(
prices=prices,
cash_to_spend=cash_to_spend,
moq=moq_buy,
cost_params=cost_params,
)
# DEBUG
# print(f'calculated purchase result: \namount_purchased: {amount_purchased.round(2)}'
# f'cash_spent: {cash_spent}')
# 4, 计算购入资产产生的交易成本，买入资产和卖出资产的交易成本率可以不同，且每次交易动态计算
fee = fee_buying + fee_selling
apply_execution_slippage(
prices, amount_purchased, amount_sold, cash_spent, cash_gained, fee, cost_params[4],
)
# DEBUG
# print(f'finished calculation: \n'
# f'cash_gained: {cash_gained.round(2)}\n'
# f'amount_sold: {amount_sold.round(2)}\n'
# f'amount_purchased: {amount_purchased.round(2)}'
# f'cash_spent: {cash_spent}\n'
# f'fee: {fee.round(2)}\n')
return cash_gained, cash_spent, amount_purchased, amount_sold, fee
@njit() # 使用numba加速反而更慢，可能是因为函数体太简单，编译和调用开销大于计算开销
def initialize_backtest_delivery_queue(cash_delivery_period: int,
stock_delivery_period: int,
share_count: int):
""" 初始化回测现金和股票交割队列，因为回测是批量进行的，因此需要通过交割队列进行快速交割计算
Parameters
----------
cash_delivery_period: int
现金交割周期
stock_delivery_period: int
股票交割周期
share_count: int
股票数量
Returns
-------
cash_delivery_queue: np.ndarray
现金交割队列
stock_delivery_queue: np.ndarray
股票交割队列
"""
cash_delivery_queue = np.zeros(shape=(cash_delivery_period + 1,), dtype='float')
stock_delivery_queue = np.zeros(shape=(stock_delivery_period + 1, share_count), dtype='float')
return cash_delivery_queue, stock_delivery_queue
@njit(nogil=True, cache=True) # 使用numba加速反而更慢，可能是因为函数体太简单，编译和调用开销大于计算开销
def process_backtest_delivery(cash_delivery_queue: np.ndarray,
stock_delivery_queue: np.ndarray,
is_new_day: bool,
day_num: int,
new_cash: float,
new_stocks: np.ndarray,
cash_delivery_period: int,
stock_delivery_period: int,
share_count: int) -> tuple[Any, np.ndarray]:
""" 处理回测现金和股票交割队列，计算达到交割期的现金和股票，并更新可用现金和可用股票
此处需要非常注意区分：股现交割的时机是发生在交易完成前还是交易完成后，因为两种时机意味着
交割判断是不同的。如果交割发生在交易完成前，那么在“换日”判断基于上一次交易是否与本次交易日期一
致，如果不一致实际上处理的是前一日的交易结果，此时应该直接进行交割换日。
但是如果在交易后执行交割，则“换日”判断基于下一次交易是否与本次交易日期一致，将本次交易结果加入
交割队列后，当下一次交易换日时，才会进行交割换日。
上述两种交割处理不同，在目前的实现中，交割发生在交易完成后，因此“换日”判断基于下一次交易是否
与本次交易日期一致。应该按照交易后交割形式实现。
Parameters
----------
cash_delivery_queue: np.ndarray
现金交割队列
stock_delivery_queue: np.ndarray
股票交割队列
is_new_day: bool
是否为新的一天，用于判断是否需要更新交割队列
day_num: int
当前的天数，用于确定交割队列中的交割位置
new_cash: float
新增的现金，用于加入交割队列
new_stocks: np.ndarray
新增的股票，用于加入交割队列
cash_delivery_period: int
现金交割周期
stock_delivery_period: int
股票交割周期
share_count: int
股票数量
Returns
-------
cash_delivery_queue: np.ndarray
更新后的现金交割队列
stock_delivery_queue: np.ndarray
更新后的股票交割队列
cash_delivered: float
达到交割期的现金
stocks_delivered: np.ndarray
达到交割期的股票数量
"""
if cash_delivery_period == 0:
cash_delivered = new_cash
else:
# 计算交割队列的起始位置，将新增现金加入交割队列起始位置
cash_in_pos = day_num % cash_delivery_period
cash_delivery_queue[cash_in_pos] += new_cash
if is_new_day:
# 如果下次交易是新的一天，查找现金交割位置执行交割，
cash_delivery_pos = (day_num + 1) % cash_delivery_period
cash_delivered = cash_delivery_queue[cash_delivery_pos]
cash_delivery_queue[cash_delivery_pos] = 0.0
else:
cash_delivered = 0.0
if stock_delivery_period == 0:
stocks_delivered = new_stocks.copy()
else:
# 计算交割队列起始位置，将新增股票加入交割队列起始位置
stock_in_pos = day_num % stock_delivery_period
stock_delivery_queue[stock_in_pos, :] += new_stocks
if is_new_day:
# 如果下次交易是新的一天，查找股票交割位置执行交割，
stock_delivery_pos = (day_num + 1) % stock_delivery_period
stocks_delivered = stock_delivery_queue[stock_delivery_pos, :].copy()
stock_delivery_queue[stock_delivery_pos, :] = np.zeros(shape=(share_count,), dtype='float')
else:
stocks_delivered = np.zeros(shape=(share_count,), dtype='float')
return cash_delivered, stocks_delivered
# @njit(nogil=True, cache=True)
def backtest_batch_steps(
signal_types: np.ndarray,
op_signals: np.ndarray,
cash_investment_array: np.ndarray,
cash_inflation_array: np.ndarray,
delivery_day_indicators: np.ndarray,
own_cashes: np.ndarray,
own_amounts_array: np.ndarray,
available_cashes: np.ndarray,
available_amounts_array: np.ndarray,
trade_prices: np.ndarray,
trade_records_array: np.ndarray,
trade_cost_array: np.ndarray,
cost_params: np.ndarray,
pt_buy_threshold: float,
pt_sell_threshold: float,
long_pos_limit: float,
short_pos_limit: float,
allow_sell_short: bool,
moq_buy: float,
moq_sell: float,
cash_delivery_period: int,
stock_delivery_period: int,
) -> None:
"""批量处理多次交易的回测计算
输入数据为整个交易过程的交易信号、交易价格、初始持仓和现金等完整的持仓表，
循环调用backtest_step()函数，同时处理现金和持仓的交割，完成整个交易清单的回测计算
Parameters
----------
signal_types: np.ndarray[int]
信号类型数组，所有交易信号的类型代码
op_signals: np.ndarray[float]
交易信号数组，所有交易信号
cash_investment_array: np.ndarray
现金投资数组，记录每一个交易信号日的现金投资金额
cash_inflation_array: np.ndarray
现金增值数组，记录每一个交易信号日相对前一个交易信号日的现金增值幅度
delivery_day_indicators: np.ndarray
交割日指标数组，记录每一个交易信号日是否为新的交割日
own_cashes: np.ndarray
持有现金清单，完整记录整个回测过程中的持有现金
own_amounts_array: np.ndarray
持有资产清单，完整记录整个回测过程中的持有资产
available_cashes: np.ndarray
可用现金清单，完整记录整个回测过程中的可用现金
available_amounts_array: np.ndarray
可用资产清单，完整记录整个回测过程中的可用资产
trade_prices: np.ndarray
交易价格清单，记录每一个运行交易记录时间戳中的各个资产的交易价格
trade_records_array: np.ndarray
交易记录清单，完整记录整个回测过程中每只股票的买卖数量记录
trade_cost_array: np.ndarray
交易成本清单，完整记录整个回测过程中的交易成本
cost_params: np.ndarray
交易成本参数，包括买入费率、卖出费率、最低买入费用、最低卖出费用、交易滑点
buy_rate: float, 交易成本：固定买入费率
sell_rate: float, 交易成本：固定卖出费率
buy_min: float, 交易成本：最低买入费用
sell_min: float, 交易成本：最低卖出费用
slippage: float, 交易成本：滑点
pt_buy_threshold: float
当交易信号类型为PT时，用于计算买入/卖出信号的强度阈值
pt_sell_threshold: float
当交易信号类型为PT时，用于计算买入/卖出信号的强度阈值
long_pos_limit: float
允许建立的多头总仓位与净资产的比值，默认值1.0，表示最多允许建立100%多头仓位
short_pos_limit: float
允许建立的空头总仓位与净资产的比值，默认值-1.0，表示最多允许建立100%空头仓位
allow_sell_short: bool
True: 允许买空卖空
False: 默认值，只允许买入多头仓位
moq_buy: float:
投资产品最小买入交易单位，moq为0时允许交易任意数额的金融产品，moq不为零时允许交易的产品数量是moq的整数倍
moq_sell: float:
投资产品最小买入交易单位，moq为0时允许交易任意数额的金融产品，moq不为零时允许交易的产品数量是moq的整数倍
cash_delivery_period: int
现金交割周期
stock_delivery_period: int
股票交割周期
Returns
-------
None,
交易的结果会被填充到传入的数组中
own_cashes: 最终持有现金清单，完整记录整个回测过程中的持有现金变动情况
available_cashes: 可用现金清单，完整记录整个回测过程中的可用现金变动情况
own_amounts_array: 最终持有资产清单，完整记录整个回测过程中的持有资产变动情况
available_amounts_array: 可用资产清单，完整记录整个回测过程中的可用资产变动情况
trade_records_array: 交易记录清单，完整记录整个回测过程中的每只股票的买卖数量变动记录
trade_cost_array: 交易费用清单，完整记录整个回测过程中的交易费用
"""
signal_count = op_signals.shape[0]
share_count = op_signals.shape[1]
# 初始化现金和股票交割队列以及交割日计数器
cash_delivery_queue, stock_delivery_queue = initialize_backtest_delivery_queue(
cash_delivery_period=cash_delivery_period,
stock_delivery_period=stock_delivery_period,
share_count=share_count,
)
day_nums = delivery_day_indicators.cumsum().astype('int')
# 开始循环处理op_signal中的每一条交易信号，获取其signal_type，执行下列步骤：
for i in range(signal_count):
# 如果当期有现金投资，则更新持有现金和可用现金
cash_investment = cash_investment_array[i]
if cash_investment > 0:
own_cashes[i] += cash_investment
available_cashes[i] += cash_investment
is_delivery_day = bool(delivery_day_indicators[i])
# 调用backtest_step函数，计算本次交易的现金变动、持仓变动和交易费用
(own_cashes[i + 1],
available_cashes[i + 1],
own_amounts_array[i + 1],
available_amounts_array[i + 1],
trade_records_array[i],
trade_cost_array[i],
cash_delivery_queue,
stock_delivery_queue) = backtest_step(
signal_type=signal_types[i],
op_signal=op_signals[i],
cash_inflation=cash_inflation_array[i],
is_delivery_day=is_delivery_day,
day_num=day_nums[i],
own_cash=own_cashes[i],
own_amounts=own_amounts_array[i],
available_cash=available_cashes[i],
available_amounts=available_amounts_array[i],
trade_prices=trade_prices[i],
cost_params=cost_params,
pt_buy_threshold=pt_buy_threshold,
pt_sell_threshold=pt_sell_threshold,
long_pos_limit=long_pos_limit,
short_pos_limit=short_pos_limit,
allow_sell_short=allow_sell_short,
moq_buy=moq_buy,
moq_sell=moq_sell,
cash_delivery_queue=cash_delivery_queue,
stock_delivery_queue=stock_delivery_queue,
cash_delivery_period=cash_delivery_period,
stock_delivery_period=stock_delivery_period,
share_count=share_count,
)
# 完成全部交易信号的处理后，输出最终的持有现金清单、持有资产清单和交易费用清单
return None
@njit(nogil=True, cache=True)
def backtest_flash_steps(
signal_types: np.ndarray,
op_signals: np.ndarray,
cash_investment_array: np.ndarray,
cash_inflation_array: np.ndarray,
delivery_day_indicators: np.ndarray,
trade_prices: np.ndarray,
cost_params: np.ndarray,
pt_buy_threshold: float,
pt_sell_threshold: float,
long_pos_limit: float,
short_pos_limit: float,
allow_sell_short: bool,
moq_buy: float,
moq_sell: float,
cash_delivery_period: int,
stock_delivery_period: int,
) -> tuple[Union[float, Any], Union[ndarray[Any, dtype[Any]], Any]]:
"""相比backtest_batch_steps()函数，以更快的速度批量处理多次交易的回测计算
该函数省略所有中间计算变量的存储，仅保存最终结果，同时省略与最终结果无关的数据存储，
从而提升计算速度、节省内存开销。
输入数据与backtest_batch_steps()函数相似，但是不包含用于记录现金、持股变动以及
交易记录和交易费用的整个数组。这些数据在函数内部仅仅作为中间变量，存储每一轮回测过
程的期初结果和期末结果，在完成全部交易信号的回测计算后，输出最后一轮回测的期末结果。
Parameters
----------
signal_types: np.ndarray[int]
信号类型数组，所有交易信号的类型代码
op_signals: np.ndarray[float]
交易信号数组，所有交易信号
cash_investment_array: np.ndarray
现金投资数组，记录每一个交易信号日的现金投资金额
cash_inflation_array: np.ndarray
现金增值数组，记录每一个交易信号日相对前一个交易信号日的现金增值幅度
delivery_day_indicators: np.ndarray
交割日指标数组，记录每一个交易信号日是否为新的交割日
trade_prices: np.ndarray
交易价格清单，记录每一个运行交易记录时间戳中的各个资产的交易价格
cost_params: np.ndarray
交易成本参数，包括买入费率、卖出费率、最低买入费用、最低卖出费用、交易滑点
buy_rate: float, 交易成本：固定买入费率
sell_rate: float, 交易成本：固定卖出费率
buy_min: float, 交易成本：最低买入费用
sell_min: float, 交易成本：最低卖出费用
slippage: float, 交易成本：滑点
pt_buy_threshold: float
当交易信号类型为PT时，用于计算买入/卖出信号的强度阈值
pt_sell_threshold: float
当交易信号类型为PT时，用于计算买入/卖出信号的强度阈值
long_pos_limit: float
允许建立的多头总仓位与净资产的比值，默认值1.0，表示最多允许建立100%多头仓位
short_pos_limit: float
允许建立的空头总仓位与净资产的比值，默认值-1.0，表示最多允许建立100%空头仓位
allow_sell_short: bool
True: 允许买空卖空
False: 默认值，只允许买入多头仓位
moq_buy: float:
投资产品最小买入交易单位，moq为0时允许交易任意数额的金融产品，moq不为零时允许交易的产品数量是moq的整数倍
moq_sell: float:
投资产品最小买入交易单位，moq为0时允许交易任意数额的金融产品，moq不为零时允许交易的产品数量是moq的整数倍
cash_delivery_period: int
现金交割周期
stock_delivery_period: int
股票交割周期
Returns
-------
tuple(float, np.ndarray),
交易的结果保存在最终的计算结果中
closing_cash: 回测结束后最终持有现金清单
closing_amounts: 回测结束后最终持有资产清单
"""
signal_count = op_signals.shape[0]
share_count = op_signals.shape[1]
# 初始化现金和股票交割队列以及交割日计数器
cash_delivery_queue, stock_delivery_queue = initialize_backtest_delivery_queue(
cash_delivery_period=cash_delivery_period,
stock_delivery_period=stock_delivery_period,
share_count=share_count,
)
day_nums = delivery_day_indicators.cumsum().astype('int')
opening_cash = 0.0
opening_available_cash = 0.0
opening_amounts = np.zeros(shape=(share_count,), dtype='float')
opening_available_amounts = np.zeros(shape=(share_count,), dtype='float')
closing_cash = 0.0
closing_amounts = np.zeros(shape=(share_count,), dtype='float')
# 开始循环处理op_signal中的每一条交易信号，获取其signal_type，执行下列步骤：
for i in range(signal_count):
# 如果当期有现金投资，则更新持有现金和可用现金
cash_investment = cash_investment_array[i]
if cash_investment > 0:
opening_cash += cash_investment
opening_available_cash += cash_investment
is_delivery_day = bool(delivery_day_indicators[i])
# 调用backtest_step函数，计算本次交易的现金变动、持仓变动和交易费用
(closing_cash,
closing_available_cash,
closing_amounts,
closing_available_amounts,
_,
_,
cash_delivery_queue,
stock_delivery_queue) = backtest_step(
signal_type=signal_types[i],
op_signal=op_signals[i],
cash_inflation=cash_inflation_array[i],
is_delivery_day=is_delivery_day,
day_num=day_nums[i],
own_cash=opening_cash,
own_amounts=opening_amounts,
available_cash=opening_available_cash,
available_amounts=opening_available_amounts,
trade_prices=trade_prices[i],
cost_params=cost_params,
pt_buy_threshold=pt_buy_threshold,
pt_sell_threshold=pt_sell_threshold,
long_pos_limit=long_pos_limit,
short_pos_limit=short_pos_limit,
allow_sell_short=allow_sell_short,
moq_buy=moq_buy,
moq_sell=moq_sell,
cash_delivery_queue=cash_delivery_queue,
stock_delivery_queue=stock_delivery_queue,
cash_delivery_period=cash_delivery_period,
stock_delivery_period=stock_delivery_period,
share_count=share_count,
)
opening_cash = closing_cash
opening_available_cash = closing_available_cash
opening_amounts = closing_amounts
opening_available_amounts = closing_available_amounts
# 完成全部交易信号的处理后，输出最终的持有现金清单、持有资产清单和交易费用清单
return closing_cash, closing_amounts
def generate_cash_invest_and_delivery_arrays(invest_cash_plan: CashPlan,
group_merge_type: str,
timing_table: pd.DataFrame) -> (tuple[np.ndarray, np.ndarray, np.ndarray]):
""" 获取现金投资和通胀率相关参数，生成投资和通胀率数组
Parameters
----------
invest_cash_plan: CashPlan
现金投资计划
group_merge_type: str
投资策略组合并类型。如果该类型为'NONE'，则表示不进行组合并操作,则交易信号的
数量可能会大于timing_table的长度，否则交易信号的数量与timing_table的长度
相同
timing_table: pd.DataFrame
操作日时间索引, 用于生成对应长度的数组
Returns
-------
cash_investment_array: np.ndarray
现金投资数组
inflation_rate_array: np.ndarray
通胀率数组
delivery_day_indicators: np.ndarray
交割日指示数组, 非交割日为0，交割日为1
"""
if group_merge_type.upper() == 'NONE':
signal_length = int(timing_table.sum().sum())
cash_plan_index = timing_table.index.repeat(timing_table.sum(axis=1).values)
else:
signal_length = len(timing_table)
cash_plan_index = timing_table.index
# 生成包含现金投资和现金通胀率数组的DataFrame
cash_plan_df = pd.DataFrame(
{'investment': np.zeros(shape=(signal_length,), dtype=float),
'inflation_rate': np.ones(shape=(signal_length,), dtype=float)},
index=cash_plan_index,
)
investment_positions = np.searchsorted(cash_plan_index, invest_cash_plan.plan.index, side='left')
for pos, amount in zip(investment_positions, invest_cash_plan.amounts):
if pos < len(cash_plan_df):
cash_plan_df.iat[pos, 0] += amount # 累加投资金额
inflation_rate = invest_cash_plan.ir
day_diffs = (cash_plan_df.index - cash_plan_df.index[0]).days
cash_plan_df['inflation_rate'] += inflation_rate * day_diffs / 365 # 年化通胀率转换为日化通胀率
cash_investment_array = cash_plan_df['investment'].to_numpy()
cash_inflation_array = cash_plan_df['inflation_rate'].to_numpy()
cash_inflation_array = cash_inflation_array / np.roll(cash_inflation_array, 1)
cash_inflation_array[0] = 1.0 # 第一天的通胀率设为1.0
day_changes = np.diff(day_diffs.values, append=day_diffs.values[-1] + 1) # 计算相邻日期的差值，最后一个日期后面添加一个新日期以确保最后一天的变化被记录
day_changes[day_changes.nonzero()] = 1 # 将非零差值设为1，表示天数变化
return cash_investment_array, cash_inflation_array, day_changes
# 定义一个Backtester类，该类包含一个operator对象，同时包含与operator回测相关的所有属性，同时提供回测结果的生成方法
[文档]class Backtester:
""" Backtester类用于对operator对象进行回测操作。
本类的属性包括回测计算中所需的所有参数，包括回测过程中产生的结果数据，这些结果数据以ndarray的形式
在对象的生命周期内长期保存，并可以反复刷新。
这个类只有在operator对象被创建之后才能被实例化，因为Backtester类需要依赖operator对象来生成交易
信号和执行交易。典型用法如下：
.. code-block:: python
operator = Operator( ... ) # 创建Operator对象
backtested = Operator.backtest( signal_count=100, share_count=10, **kwargs) # 创建Backtester对象
# get backtest raw results:
backtested.cash_investment_array
backtested.own_cashes
...
# get backtest results as DataFrame:
result_df = backtested.value_records()
trade_log_df = backtested.trade_logs()
trade_summary_df = backtested.trade_summary()
Attributes
----------
op: Operator
交易操作对象，包含交易信号生成和交易执行的逻辑
"""
def __init__(self,
op: Operator,
shares: list[str],
cash_plan: CashPlan,
cash_investment_array: np.ndarray,
cash_inflation_array: np.ndarray,
delivery_day_indicators: np.ndarray,
cost_params: np.ndarray, # 交易成本参数
signal_parsing_params: dict, # 交易信号解析参数
trading_moq_params: dict, # 交易最小单位参数
trading_delivery_params: dict, # 交易交割参数
trade_price_data: np.ndarray, # 交易价格数据
benchmark_data: Optional[Union[pd.DataFrame, pd.Series]] = None,
evaluate_price_data: Optional[pd.DataFrame] = None,
enable_tracing: bool = False,
logger: Optional[logging.Logger] = None):
""" 初始化Backtester对象，设置operator对象和回测参数，初始化回测结果存储表格
Parameters
----------
op: Operator
交易操作对象，包含交易信号生成和交易执行的逻辑
shares: list[str]
交易标的列表，包含所有交易标的的代码
cash_plan: CashPlan,
现金投资计划
benchmark_data: pd.DataFrame or pd.Series
用于评价回测结果的业绩基准价格，频率为日频，每日收盘价，其索引为回测开始日到结束日的所有交易日日期，列名为benchmark
evaluate_price_data: pd.DataFrame, optional
用于评价回测结果的日频收盘价数据，索引为交易日15:00:00，列为资产代码
cash_investment_array: np.ndarray
现金投资数组，记录每一个交易信号日的现金投资金额
cash_inflation_array: np.ndarray
现金增值数组，记录每一个交易信号日相对前一个交易信号日的现金增值幅度
delivery_day_indicators: np.ndarray
交割日指标数组，记录每一个交易信号日是否为新的交割日
cost_params: np.ndarray
交易成本参数，包括买入费率、卖出费率、最低买入费用、最低卖出费用、交易滑点
buy_rate: float, 交易成本：固定买入费率
sell_rate: float, 交易成本：固定卖出费率
buy_min: float, 交易成本：最低买入费用
sell_min: float, 交易成本：最低卖出费用
slippage: float, 交易成本：滑点
signal_parsing_params: dict
交易信号解析参数字典，包含解析交易信号所需的所有参数，通常是parse_signal_parsing_params()函数的输出
trading_moq_params: dict
交易最小单位参数字典，包含交易最小单位相关的所有参数，通常是parse_trading_moq_params()函数的输出
trading_delivery_params: dict
交易交割参数字典，包含交易交割相关的所有参数，通常是parse_trading_delivery_params()函数的输出
trade_price_data: np.ndarray
交易价格数据，记录每一个运行交易记录时间戳中的各个资产的交易价格
enable_tracing: bool, optional, default=False
是否启用回测过程的性能追踪功能，默认值为False
logger: Optional[logging.Logger]
可选的日志记录器对象，用于记录回测过程中的日志信息
"""
# 参数基础校验
assert isinstance(op, Operator), "op must be an instance of Operator"
if isinstance(shares, str):
shares = str_to_list(shares)
assert isinstance(shares, list) and all(isinstance(s, str) for s in shares), "shares must be a list of strings"
# benchmark 必须是一个pd.Series，如果是DataFrame，则转换为Series
if isinstance(benchmark_data, pd.DataFrame):
if benchmark_data.shape[1] != 1:
raise ValueError("benchmark_data DataFrame must have only one column")
benchmark_data = benchmark_data.iloc[:, 0]
if benchmark_data is not None and not isinstance(benchmark_data, pd.Series):
raise TypeError("benchmark_data must be a pandas Series or DataFrame with one column")
# 参数一致性校验
n_signals = op.get_signal_count()
share_count = len(shares)
arrays_to_check = [
("cash_investment_array", cash_investment_array, (n_signals,)),
("cash_inflation_array", cash_inflation_array, (n_signals,)),
("delivery_day_indicators", delivery_day_indicators, (n_signals,)),
("trade_price_data", trade_price_data, (n_signals, share_count))
]
for name, arr, shape in arrays_to_check:
if not isinstance(arr, np.ndarray):
raise TypeError(f"{name} must be a numpy array")
if arr.shape != shape:
raise ValueError(f"{name} should have shape {shape}, but got {arr.shape}")
self.op = op
self.op_signals: Optional[np.ndarray] = None # 回测生成的交易信号表格，实际上在op内也可以存储
self.shares = shares
self.cash_investment_array = cash_investment_array
self.cash_inflation_array = cash_inflation_array
self.delivery_day_indicators = delivery_day_indicators
self.cost_params = cost_params
self.signal_parsing_params = signal_parsing_params
self.trading_moq_params = trading_moq_params
self.trading_delivery_params = trading_delivery_params
self.trade_price_data = trade_price_data
self.logger = logger
self.op_run_time = 0.0 # operator运行时间，单位秒
self.backtest_run_time = 0.0 # 回测运行时间，单位秒
# 1，检查operator对象是否已经准备好，否则raise error, TOOD: 是否有必要？
# op.is_ready(raise_error=True)
if logger is not None:
logger.info('Start backtest operator...')
# 2，从operator对象读取交易运行计划和时间表，获取交易信号长度，生成用于存储交易信号和持仓数据的表格
self.op_schedule = op.group_timing_table.index
self.n_signals = op.get_signal_count()
self.share_count = len(self.shares)
# 3.1 现金和股票持仓历史记录表
shape_assets = (self.n_signals + 1, self.share_count)
shape_cashes = (self.n_signals + 1,)
self.own_cashes = np.zeros(shape=shape_cashes, dtype=float)
self.own_amounts_array = np.zeros(shape=shape_assets, dtype=float)
self.available_cashes = np.zeros(shape=shape_cashes, dtype=float)
self.available_amounts_array = np.zeros(shape=shape_assets, dtype=float)
# 3.2 交易过程数据记录表，包括交易记录、交易成本等
shape_signals = (self.n_signals, self.share_count)
self.trade_records_array = np.zeros(shape_signals, dtype=float) # 记录每次交易的买卖数量
self.trade_cost_array = np.zeros(shape_signals, dtype=float) # 记录每次交易的交易成本
self.trade_price_array = np.zeros(shape_signals, dtype=float) # 记录每次交易的成交价格，未成交为0，dynamic数据类型的operator需要用到
# 4, 回测交易最终结果：评价指标、交易日志和交易汇总记录
self.backtest_result: dict = {}
self.trade_log_df: Optional[pd.DataFrame] = None
self.summary_df: Optional[pd.DataFrame] = None
self.trace_df: Optional[pd.DataFrame] = None
# 5, 其他相关属性（需要增加数据匹配性校验）
self.cash_plan = cash_plan
self.benchmark_data = benchmark_data
self.evaluate_price_data = evaluate_price_data
self.enable_tracing = enable_tracing
if logger is not None:
logger.info('Start backtest operator...')
[文档] def run(self) -> 'Backtester':
""" 执行回测计算，生成回测结果数据并存入对象属性中"""
self.op.set_shares(self.shares)
if self.enable_tracing:
self.op.enable_tracing()
else:
self.op.disable_tracing()
# 1，如果operator的交易信号不依赖于回测数据，调用函数backtest_operator_independently()处理回测信号
if not self.op.check_dynamic_data():
if self.logger is not None:
self.logger.info('Backtest operator with only static data...')
signals = self._backtest_static_operator()
# 2，如果operator的交易信号依赖于回测数据，调用函数backtest_operator_dependently()处理回测信号
else:
if self.logger is not None:
self.logger.info('Backtest operator with dynamic data dependence...')
signals = self._backtest_dynamic_operator()
self.op_signals = signals
if self.logger is not None:
self.logger.info('Backtest completed.')
return self
[文档] def clear_backtest_buffers(self):
""" 清除回测结果缓存数据，将回测结果数据重置为空数组，以便重新进行回测计算
Returns
-------
None
"""
self.op_signals = None
self.own_cashes.fill(0.0)
self.own_amounts_array.fill(0.0)
self.available_cashes.fill(0.0)
self.available_amounts_array.fill(0.0)
self.trade_records_array.fill(0.0)
self.trade_cost_array.fill(0.0)
self.backtest_result.clear()
self.trade_log_df = None
self.summary_df = None
def _backtest_static_operator(self) -> np.ndarray:
"""处理operator的交易信号仅包含静态数据类型（不依赖交易结果的数据）的情况:
"""
# 1，调用operator.run()生成完整的交易信号清单，并计算保存运行时间
stypes = np.zeros(self.op.get_signal_count(), dtype=int)
s_indices = np.zeros(self.op.get_signal_count(), dtype=int)
signals = np.zeros((self.op.get_signal_count(), self.share_count), dtype=float)
signal_index = 0
st = time.time()
for stype, s_index, signal in self.op.run_strategies(steps=range(len(self.op.group_timing_table))):
stypes[signal_index] = SIGNAL_TYPE_ID[stype]
s_indices[signal_index] = s_index
signals[signal_index, :] = signal
signal_index += 1
et = time.time()
self.op_run_time = et - st
# 2，调用backtest_batch_steps()进行回测，填充回测结果清单
st = time.time()
backtest_batch_steps(
signal_types=stypes,
op_signals=signals,
cash_investment_array=self.cash_investment_array,
cash_inflation_array=self.cash_inflation_array,
delivery_day_indicators=self.delivery_day_indicators,
own_cashes=self.own_cashes,
available_cashes=self.available_cashes,
own_amounts_array=self.own_amounts_array,
available_amounts_array=self.available_amounts_array,
trade_prices=self.trade_price_data,
trade_records_array=self.trade_records_array,
trade_cost_array=self.trade_cost_array,
cost_params=self.cost_params,
**self.signal_parsing_params,
**self.trading_moq_params,
**self.trading_delivery_params,
)
et = time.time()
self.backtest_run_time = et - st
return signals
def _backtest_dynamic_operator(self) -> np.ndarray:
"""处理operator的交易信号包含动态数据类型(依赖交易结果的数据类型)的情况:
根据输入参数逐步调用operator.run()生成交易信号清单，然后调用backtest_batch_steps()进行回测"""
# TODO: 实现交易过程动态数据的获取
# 1，读取初始持仓和现金数据，更新operator中的依赖性历史数据
signals = np.zeros((self.op.get_signal_count(), self.share_count), dtype=float)
# 为 Operator 注入完整的交易过程数据源与时间索引，供策略通过 get_data('proc.xxx', ...) 访问。
# 注意：这里不改变原有 dynamic data buffer 机制，仅额外提供 process data 视图。
try:
self.op._process_time_index = self.op.op_signal_index.get_level_values(0).to_numpy()
except Exception:
self.op._process_time_index = None
if hasattr(self.op, "_process_data_sources"):
self.op._process_data_sources = {
"own_cashes": self.own_cashes,
"available_cashes": self.available_cashes,
"own_amounts": self.own_amounts_array,
"available_amounts": self.available_amounts_array,
"trade_records": self.trade_records_array,
"trade_costs": self.trade_cost_array,
# 使用实际成交价格作为交易价格过程数据
"trade_prices": self.trade_price_array,
# 使用交易模拟价格作为估值价格，用于 position_value / total_value 一类派生量
"price_data": self.trade_price_data,
}
self.op.prepare_dynamic_data_buffer(
trade_records=self.trade_records_array, # 成交量
trade_prices=self.trade_price_array, # 成交价格
own_cashes=self.own_cashes, # 持有现金
available_cashes=self.available_cashes,
holding_positions=self.own_amounts_array,
available_positions=self.available_amounts_array,
)
cash_delivery_queue, stock_delivery_queue = initialize_backtest_delivery_queue(
share_count=self.share_count,
**self.trading_delivery_params,
)
day_nums = self.delivery_day_indicators.cumsum()
timer = FunctionTimer()
bt_step = 0
# 循环执行下面步骤，直至完整生成回测结果清单
for i in range(len(self.op.group_timing_table)):
# 1，调用operator.run_strategy()生成当前交易信号，注意同一时刻可能会有多组信号生成
# print(f'running / backtest step {i+1}/{bt_step + 1}...')
for result in timer.time_function('op_run', self.op.run_strategy, step_index=i):
# print(f'got result from op.run_strategy: {result}')
stype, s_index, signal = result
# 2，开始回测，判断是否有资金投入，如果有，更新持有现金和可用现金
cash_investment = self.cash_investment_array[bt_step]
if cash_investment > 0:
self.own_cashes[bt_step] += cash_investment
self.available_cashes[bt_step] += cash_investment
signal_type = SIGNAL_TYPE_ID[stype]
is_delivery_day = bool(self.delivery_day_indicators[bt_step])
signals[bt_step, :] = signal
# 3，调用backtest_step()回测当前交易信号的结果，生成当前交易回测结果
(
self.own_cashes[bt_step + 1],
self.available_cashes[bt_step + 1],
self.own_amounts_array[bt_step + 1],
self.available_amounts_array[bt_step + 1],
self.trade_records_array[bt_step],
self.trade_cost_array[bt_step],
cash_delivery_queue,
stock_delivery_queue,
) = timer.time_function(
'backtest',
backtest_step,
signal_type=signal_type,
op_signal=signal,
cash_inflation=self.cash_inflation_array[bt_step],
is_delivery_day=is_delivery_day,
day_num=day_nums[bt_step],
own_cash=self.own_cashes[bt_step],
own_amounts=self.own_amounts_array[bt_step, :],
available_cash=self.available_cashes[bt_step],
available_amounts=self.available_amounts_array[bt_step, :],
trade_prices=self.trade_price_data[bt_step, :],
cost_params=self.cost_params,
cash_delivery_queue=cash_delivery_queue,
stock_delivery_queue=stock_delivery_queue,
share_count=self.share_count,
**self.signal_parsing_params,
**self.trading_moq_params,
**self.trading_delivery_params,
)
bt_step += 1
# # 4，更新operator中的依赖性历史数据，主要是trade_prices_array数据（成交价格数据，因为这个价格需要计算出来）
self.trade_price_array[:] = np.abs(np.sign(self.trade_records_array)) * self.trade_price_data
time = timer.get_stats()
self.op_run_time = time['op_run']
self.backtest_run_time = time['backtest']
# 5，返回signals，因为完整的回测结果清单已经保存在作为参数传入的几个数组中
return signals
# 生成回测结果的各种评价指标，直接快速计算返回回测的各项结果指标
[文档] def trade_result_final_value(self):
""" 直接快速计算返回回测的终值结果"""
final_value = (self.trade_price_data * self.own_amounts_array[1:]).sum(axis=1) + self.own_cashes[1:]
return final_value[-1]
[文档] def trade_result_volatility(self):
""" 直接快速计算返回回测的波动率结果"""
value_history = (self.trade_price_data * self.own_amounts_array[1:]).sum(axis=1) + self.own_cashes[1:]
rolled_value_history = np.roll(value_history, 1)
returns = (value_history - rolled_value_history) / rolled_value_history
returns[0] = 0.0 # 第一天的收益率设为0.0
volatility = returns.std() * np.sqrt(252)
return volatility
[文档] def trade_result_max_drawdown(self):
""" 直接快速计算返回回测的最大回撤结果"""
value_history = (self.trade_price_data * self.own_amounts_array[1:]).sum(axis=1) + self.own_cashes[1:]
rolling_max = np.maximum.accumulate(value_history)
drawdown = (value_history - rolling_max) / rolling_max
max_drawdown = drawdown.min()
return max_drawdown
# 生成更加结构化的DataFrame型交易结果数据，以便用于结果的评价及后续处理，
[文档] def trade_result_df(self) -> pd.DataFrame:
""" 根据回测结果生成资产价值记录，输出内容为DataFrame格式
Returns
-------
value_history: pd.DataFrame
交易模拟结果数据
"""
if self.evaluate_price_data is None:
value_history = pd.DataFrame(self.own_amounts_array[1:],
index=self.op.op_signal_index.get_level_values(0),
columns=self.shares)
value_history['cash'] = self.own_cashes[1:]
value_history['value'] = (self.trade_price_data * self.own_amounts_array[1:]).sum(axis=1) + self.own_cashes[1:]
value_history['fee'] = self.trade_cost_array.sum(axis=1)
value_history = value_history.groupby(value_history.index).last()
return value_history
daily_index = self.evaluate_price_data.index
step_times = pd.to_datetime(self.op.op_signal_index.get_level_values(0))
step_times_values = step_times.to_numpy()
daily_values_ts = daily_index.to_numpy()
# 对于第一个交易信号之前的日期，使用初始持仓（索引0）；
# 对于两个交易信号之间的日期，使用最近一次交易后的持仓；
# 对于最后一个交易信号之后的日期，使用最后一次交易后的持仓。
pos_idx = np.searchsorted(step_times_values, daily_values_ts, side='right')
pos_idx = np.clip(pos_idx, 0, self.own_amounts_array.shape[0] - 1)
daily_positions = self.own_amounts_array[pos_idx, :]
daily_cash = self.own_cashes[pos_idx]
# 将每一步交易费用按“日期”聚合为“每日总费用”，再与日频索引按日期对齐
step_dates = step_times.normalize()
step_fee = self.trade_cost_array.sum(axis=1)
fee_by_date = pd.Series(step_fee, index=step_dates).groupby(level=0).sum()
daily_dates = daily_index.normalize()
daily_fee = fee_by_date.reindex(daily_dates).fillna(0.0)
# 使用评价用日频收盘价构造日频价格序列
daily_prices = self.evaluate_price_data.reindex(daily_index).reindex(columns=self.shares)
price_array = np.nan_to_num(daily_prices.values, nan=0.0)
daily_values = (price_array * daily_positions).sum(axis=1) + daily_cash
# 一次性拼接持仓列与价格列，避免逐列插入导致 DataFrame 碎片化
positions_df = pd.DataFrame(daily_positions, index=daily_index, columns=self.shares)
price_df = daily_prices.reindex(columns=self.shares).rename(columns=lambda c: 'p-' + c)
value_history = pd.concat([positions_df, price_df], axis=1)
value_history['cash'] = daily_cash
value_history['value'] = daily_values
value_history['fee'] = daily_fee.values
return value_history
[文档] def trace_result_df(self) -> Optional[DataFrame]:
""" 根据回测结果生成交易过程记录，输出内容为DataFrame格式
trace 行与 op_signal_index 的对齐由 Operator 在写入时保证（update_trace_step 使用
全局 signal 行号），此处仅按策略 concat 后设置 index 为 op_signal_index。
Returns
-------
trade_trace: pd.DataFrame
交易模拟过程数据
"""
if not self.enable_tracing:
return self.trace_df
op_signal_index = self.op.op_signal_index
trace_dfs = [s.get_trace_data() for s in self.op.strategies]
if not trace_dfs:
self.trace_df = pd.DataFrame(index=op_signal_index)
return self.trace_df
trade_trace = pd.concat(trace_dfs, axis=1)
trade_trace.index = op_signal_index
self.trace_df = trade_trace
return self.trace_df
[文档] def evaluate_result(self, indicators: str) -> dict:
"""生成交易结果的评价报告，保存在self.evaluate_result属性中
Parameters
----------
indicators: str
回测结果评价指标，详情参见qteasy.evaluate.evaluate()函数
Returns
-------
"""
self.backtest_result.update(
evaluate(
looped_values=self.trade_result_df(),
hist_benchmark=self.benchmark_data,
cash_plan=self.cash_plan,
indicators=indicators,
)
)
self.backtest_result['op_run_time'] = self.op_run_time
self.backtest_result['loop_run_time'] = self.backtest_run_time
return self.backtest_result
# 生成回测结果的明细报告，包括纯文本形式的报告和图表形式的报告
[文档] def report_result(self,
trade_log: str = None,
trade_summary: str = None) -> str:
""" 生成回测结果的明细报告，报告为纯文本格式，可以使用print命令打印
Parameters
----------
trade_log: str, optional
交易日志文件的存储路径，默认值为None，如果给出该路径，则在报告中打印交易日志的存储路径
trade_summary: str, optional
交易汇总记录文件的存储路径，默认值为None，如果给出，则在报告中打印交易汇总记录的存储路径
Returns
-------
report_str: str
以打印格式排版的回测结果报告
"""
if self.backtest_result.get('complete_values') is not None:
self.backtest_result['report'] = _loop_report_str(
loop_results=self.backtest_result,
)
return self.backtest_result['report']
else:
return 'Complete evaluation of backtest result is not created!'
[文档] def plot_result(self, plot_title: str,
show_positions: bool,
buy_sell_markers: bool) -> None:
""" 以图表形式生成交易结果
Parameters
----------
plot_title: str
图表的标题名称
show_positions: bool
是否显示持股仓位区间信息，如果设置为True，则在收益率曲线图上
以红色/绿色条带显示区间的持仓类型（绿色表示持多仓，红色表示持
空仓）颜色越深持仓比例越高
buy_sell_markers: bool
是否在收益率曲线图上显示买卖点，如果设置为True，则在收益率曲
线图上以红绿色小箭头标示出买卖点
Returns
-------
None
"""
if self.backtest_result.get('complete_values') is not None:
_plot_loop_result(
loop_results=self.backtest_result,
plot_title=plot_title,
show_positions=show_positions,
buy_sell_markers=buy_sell_markers,
)
else:
err = RuntimeError('Complete evaluation of backtest result is not created!')
raise err
# 根据回测结果生成交易日志，包含更加完整的交易记录，输出内容为DataFrame格式，并且可以保存为csv文件
[文档] def generate_trade_logs(
self,
save_to_file_path: Union[str, None] = None,
) -> DataFrame:
"""根据回测结果生成交易日志，交易日志是一份完整的交易记录文件，包含每一个交易期间的下列信息。
每一个交易期间包含 8 行数据，分别为：
- ``0, trade signal``：每一支股票的当期交易信号
- ``1, price``：每一支股票的当期交易价格
- ``2, traded amounts``：每一支股票的当期交易数量，如果没有交易则为 0
- ``3, cash changed``：每一支股票的当期现金变动金额，买入为负数，卖出为正数
- ``4, trade cost``：每一支股票的当期交易费用
- ``5, own amounts``：每一支股票的当期末持有数量
- ``6, available amounts``：每一支股票的当期末可用数量
- ``7, summary``：当期每一支股票的持仓价值，同时包含汇总数据（当期末持有现金、可用现金、总资产价值）
以上信息以 DataFrame 形式保存，行索引为多级索引，第一/二层为时间/策略组索引，第三层为上述 8 个数据类别。
交易日志文件可以被保存为 csv 格式，文件名为 ``trade_log.csv``。
Parameters
----------
save_to_file_path: str, optional
如果提供了文件路径，则将交易日志保存为CSV文件，默认值为None
Returns
-------
trade_log: pd.DataFrame
交易模拟结果数据
"""
if self.logger:
# create share trading logs:
self.logger.info(f'generating detailed trading log ...')
if self.share_count == 0:
raise ValueError('shares list is empty, cannot create trade logs!')
# 生成 trade log 详细表的股票持仓变化详情部分 （每支股票每期的交易信号、价格、交易数量、交易费用、期末持有数量、期末可用数量、持仓价值等）
op_signal_index = self.op.op_signal_index
trade_signal_df = pd.DataFrame(self.op_signals,
index=op_signal_index,
columns=self.shares)
trade_price_df = pd.DataFrame(np.round(self.trade_price_data, 3),
index=op_signal_index,
columns=self.shares)
own_amounts_df = pd.DataFrame(np.round(self.own_amounts_array[1:], 3),
index=op_signal_index,
columns=self.shares)
available_amounts_df = pd.DataFrame(np.round(self.available_amounts_array[1:], 3),
index=op_signal_index,
columns=self.shares)
trade_records_df = pd.DataFrame(np.round(self.trade_records_array, 3),
index=op_signal_index,
columns=self.shares)
trade_cost_df = pd.DataFrame(np.round(self.trade_cost_array, 3),
index=op_signal_index,
columns=self.shares)
cash_changed_df = pd.DataFrame(np.round(-trade_price_df * trade_records_df - self.trade_cost_array, 3),
index=op_signal_index,
columns=self.shares)
amounts_value_df = pd.DataFrame(np.round(trade_price_df * self.own_amounts_array[1:], 3),
index=op_signal_index,
columns=self.shares)
combined_data = pd.concat(
objs=[trade_signal_df,
trade_price_df,
trade_records_df,
cash_changed_df,
trade_cost_df,
own_amounts_df,
available_amounts_df,
amounts_value_df, ],
keys=['0, trade signal',
'1, price',
'2, traded amounts',
'3, cash changed',
'4, trade cost',
'5, own amounts',
'6, available amounts',
'7, summary'],
)
combined_data = combined_data.reorder_levels([1, 2, 0]).sort_index(level=0)
# 生成 trade log 详细表的每期汇总数据部分（当期现金投入、期末持有现金、期末可用现金、期末总价值）
add_investments = pd.Series(self.cash_investment_array,
index=op_signal_index,
name='add. invest')
own_cash_series = pd.Series(np.round(self.own_cashes[1:], 3),
index=op_signal_index,
name='own cash')
available_cash_series = pd.Series(np.round(self.available_cashes[1:], 3),
index=op_signal_index,
name='available cash')
total_values = (self.trade_price_data * self.own_amounts_array[1:]).sum(axis=1) + self.own_cashes[1:]
total_value_series = pd.Series(np.round(total_values, 3),
index=op_signal_index,
name='value')
summary_data = [add_investments, own_cash_series, available_cash_series, total_value_series]
if self.enable_tracing:
trace_df = self.trace_result_df()
if trace_df is not None:
summary_data.append(trace_df)
self.summary_df = pd.concat(
objs=summary_data,
axis=1,
)
self.summary_df = self.summary_df.assign(summary='7, summary').set_index('summary', append=True)
self.summary_df.index.names = [None, None, None]
# 上面将summary_df的索引变为多级索引，第三层为'7, summary'，与combined_data的第三层索引对应，以便join
self.trade_log_df = self.summary_df.join(combined_data, how='outer', sort=False)
if save_to_file_path is not None:
self.trade_log_df.to_csv(save_to_file_path, encoding='utf-8')
if self.logger:
self.logger.info(f'trade log saved to {save_to_file_path}')
self.backtest_result['trade_log'] = save_to_file_path #
return self.trade_log_df
# 根据回测结果生成交易汇总表，输出内容为DataFrame格式，并且可以保存为csv文件
[文档] def generate_trade_summary(
self,
share_names: Union[list[str], None] = None,
save_to_file_path: Union[str, None] = None,
) -> pd.DataFrame:
""" 生成 trade summary 交易摘要表 (一个更加紧凑的交易汇总表，包含每次交易的关键信息，
以一种更加易于人类阅读的方式呈现，并过滤掉无交易的记录)，函数的输入trade_log_df是函数
generate_trade_logs()的返回值。
Parameters
----------
share_names: list[str], optional
交易标的名称列表, 如果为None，则使用“N/A”作为名称
save_to_file_path: str, optional
如果提供了文件路径，则将交易摘要表保存为CSV文件，默认值为None，不保存文件
"""
if self.logger is not None:
# create share trading logs:
self.logger.info(f'generating abstract trading log ...')
if self.share_count == 0:
raise ValueError('shares list is empty, cannot create trade summary!')
if any(share not in self.trade_log_df.columns for share in self.shares):
missing_share = [share for share in self.shares if share not in self.trade_log_df.columns]
raise KeyError(
f'some shares ({missing_share}) are not in trade_log_df columns, cannot create trade summary!')
# 处理share_names
if share_names is None:
share_names = ['N/A' for _ in self.shares]
share_logs = []
# trade_log_df_no_duplicate = self.trade_log_df[~self.trade_log_df.index.duplicated(keep='last')]
for share, share_name in zip(self.shares, share_names):
share_df = self.trade_log_df[share].unstack()
share_df = share_df[share_df['2, traded amounts'] != 0]
share_df['code'] = share
share_df['name'] = share_name
share_logs.append(share_df)
re_columns = ['code',
'name',
'0, trade signal',
'1, price',
'2, traded amounts',
'3, cash changed',
'4, trade cost',
'5, own amounts',
'6, available amounts',
'7, summary']
op_log_shares_abs = pd.concat(share_logs).reindex(columns=re_columns)
self.summary_df.index = self.summary_df.index.droplevel(-1) # 去掉index中的’7, summary‘层级以便join
self.summary_df = self.summary_df.join(op_log_shares_abs, how='right', sort=True)
if save_to_file_path is not None:
self.summary_df.to_csv(save_to_file_path, encoding='utf-8')
if self.logger is not None:
self.logger.info(f'trade summary saved to {save_to_file_path}')
self.backtest_result['trade_summary'] = save_to_file_path #
return self.summary_df
[文档] def save_complete_values(self, save_to_file_path: Optional[str] = None) -> Optional[str]:
""" 将 complete_values 保存为 CSV 文件（当 trade_log=True 时由 qt_operator 调用）
Parameters
----------
save_to_file_path: str, optional
保存路径，若为 None 则不写入
Returns
-------
str or None
成功时返回保存路径，否则返回 None
"""
cv = self.backtest_result.get('complete_values')
if save_to_file_path is None or cv is None or (isinstance(cv, pd.DataFrame) and cv.empty):
if self.logger:
self.logger.debug(
'save_complete_values skipped: path=%s, complete_values present=%s',
save_to_file_path,
cv is not None and (not isinstance(cv, pd.DataFrame) or not cv.empty),
)
return None
cv.to_csv(save_to_file_path, encoding='utf-8')
self.backtest_result['complete_values_file'] = save_to_file_path
if self.logger:
self.logger.info(f'complete values (value curve) saved to {save_to_file_path}')
return save_to_file_path
